Steel Deck

Steel Deck


Whether it is roofing, flooring, or ceilings, Vulcraft provides a variety of steel deck profiles and depths to meet your customers' unique needs. Vulcraft manufactures many different types of deck, including roof deck, floor deck, composite floor deck and cellular deck. By their nature, our metal decking is noncombustible, assuring architects, engineers, and owners excellent fire ratings.

Vulcraft designs and manufactures its steel deck in accordance with the specifications of the Steel Deck Institute. Vulcraft also provides a full line of deck accessories, including end closures and pour stops.

Find us at:

Steel Roof Deck

Vulcraft provides a number of roof deck profiles, each one with unique benefits designed to meet the requirements for a wide variety of projects. All of these deck profiles are available in several finish options.

Vulcraft Roof Decks are designed in accordance with the ANSI/Steel Deck Institute RD-2017.

Vulcraft's standard, acoustical and non-acoustical decks are IAPMO UES ER-652 UL and/or FM listed. Vulcraft's Dovetail Roof Deck, acoustical and non-acoustical, are IAPMO UES ER-423, UL and/or FM listed. See datasheets for specific listings.

See Roof Deck Design Information below for a quick reference on Vulcraft’s roof deck options. For more customized design solutions, visit our Online Design Tools.

ROOF DECK DESIGN INFORMATION (ASD)

B Deck profiles are 1.5-inch deep structural roof deck that provide both vertical load and diaphragm shear capacity.  The wide ribs make the profile an ideal structural substrate to uniformly support roofing systems applied on top of the deck.  Type B profiles are typically used for span conditions of 10 feet or less.

Acoustical version of this deck (1.5BA, 1.5BIA and 1.5PLBA) are available. A variety of side-lap features are also available including nested (1.5B), interlocking (1.5BI), and PunchLok II connection (1.5PLB). Learn More About the PunchLok II System.

1.5F (intermediate rib) and 1.5A (narrow rib) deck are still available from Vulcraft. For more information about these deck types, reach out to one of our experts.

N Deck profiles have 3-inch deep ribs making them ideal for span conditions greater than 10 feet or when a specific aesthetic look is desired.  The narrow low flutes and wide high flutes create a very uniform look from the bottom side.

Our 32” wide N deck adds an extra eight inches to the width of the deck, which translates to greater coverage per sheet, reducing the numbers of sheets that have to be laid.

Acoustical versions of this deck (3NLA-32, 3NIA-32, 3PLNA-32, 3NA-24 and 3NIA-24) are available. A variety of side-lap features are also available including nested (3NL-32, 3N-24), interlocking (3NI-32, 3NI-24) and PunchLok II (3PLN-32). Learn More About the PunchLok II System

Dovetail Deck profiles create a highly effective and value-added deck type for roof systems. Its list of benefits include significant strength and capacity at longer spans, highly aesthetic underside for exposed ceilings, and unique and effective hanging solution opportunities.

This deck comes in two profiles, 2.0D (2.0” deep) and 3.5D (3.5” deep). These profiles are also available with acoustical properties (2.0DA & 3.5DA). Learn more about Dovetail Deck

ROOF DECK DESIGN INFORMATION (LRFD)

B Deck profiles are 1.5-inch deep structural roof deck that provide both vertical load and diaphragm shear capacity.  The wide ribs make the profile an ideal structural substrate to uniformly support roofing systems applied on top of the deck.  Type B profiles are typically used for span conditions of 10 feet or less.

A variety of acoustical properties (1.5BA, 1.5BIA and 1.5PLBA) and side-lap features are also available including nested (1.5B), interlocking (1.5BI) and PunchLok II connection (1.5PLB). Learn More About the PunchLok II System.

1.5F (intermediate rib) and 1.5A (narrow rib) deck are still available from Vulcraft. For more information about these deck types, reach out to one of our experts.

N Deck profiles have 3-inch deep ribs making them ideal for span conditions greater than 10 feet or when a specific aesthetic look is desired.  The narrow low flutes and wide high flutes create a very uniform look from the bottom side.

Our 32” wide N deck adds an extra eight inches to the width of the deck, which translates to greater coverage per sheet, reducing the numbers of sheets that have to be laid.

Acoustical versions of this deck (3NLA-32, 3NIA-32, 3PLNA-32, 3NA-24 and 3NIA-24) are available. A variety of side-lap features are also available including nested (3NL-32, 3N-24), interlocking (3NI-32, 3NI-24) and PunchLok II connection (3PLN-32). Learn More About the PunchLok II System

Dovetail Deck profiles create a highly effective and value-added deck type for roof systems. Its list of benefits include significant strength and capacity at longer spans, highly aesthetic underside for exposed ceilings, and unique and effective hanging solution opportunities.

This deck comes in two profiles, 2.0D (2.0” deep) and 3.5D (3.5” deep). These profiles are also available with acoustical properties (2.0DA & 3.5DA). Learn more about Dovetail Deck




Composite Floor Deck

Vulcraft produces a wide variety of composite deck that works compositely with the concrete slab to produce an efficient and economical structural floor solution for elevated floor systems. These decks come in a variety of finish options.

Vulcraft Composite Floor Decks are IAPMO (IAPMO UES ER-423 and IAPMO UES ER-652) and UL Listed. These decks are designed in accordance with the ANSI/Steel Deck Institute C-2017.

See Composite Deck Design Information below for a quick reference on Vulcraft's composite floor deck options. For custom design information, visit our Online Design Tools.

COMPOSITE DECK DESIGN INFORMATION (ASD)

1.5 Composite Floor Deck is 1.5-inches deep and is available with three options for side lap connections, nested (1.5VL), interlocking (1.5VLI) and PunchLok II connection (1.5PLVLI). Learn More About the PunchLok II System

1.5VLR is the inverse of 1.5VL deck. This profile provides the wider parts of the ribs toward the bottom of the deck, allowing for a greater amount of concrete to be included in the final deck-slab.

2VLI and 3VLI Composite Deck are popular deck profiles used for elevated floor slabs. The 2VLI and 3VLI profiles are 2-inches deep and 3-inches deep, respectively. This decking is offered with three options for side lap connections, interlocking (2VLI and 3VLI), nested (2VLJ and 3VLJ) and PunchLok II connection (2PLVLI and 3PLVLI).
Learn More About the PunchLok II System

FormLok Dovetail Deck (2.0D and 3.5D) profiles are 2-inches deep and 3.5-inches deep, respectively. These profiles create a highly effective and value-added deck type for elevated floor systems. This deck type provides significant strength and capacity at longer spans and unique and effective hanging solution opportunities. Learn more about Dovetail Deck

COMPOSITE DECK DESIGN INFORMATION (LRFD)

1.5 Composite Floor Deck is 1.5-inches deep and is available with three options for side lap connections, nested (1.5VL), interlocking (1.5VLI) and PunchLok II connection (1.5PLVLI). Learn More About the PunchLok II System

1.5VLR is the inverse of 1.5VL deck. This profile provides the wider parts of the ribs toward the bottom of the deck, allowing for a greater amount of concrete to be included in the final deck-slab.

2VLI and 3VLI Composite Deck are popular deck profiles used for elevated floor slabs. The 2VLI and 3VLI profiles are 2-inches deep and 3-inches deep, respectively. This decking is offered with three options for side lap connections, interlocking (2VLI and 3VLI), nested (2VLJ and 3VLJ) and PunchLok II connection (2PLVLI and 3PLVLI).
Learn More About the PunchLok II System

FormLok Dovetail Deck (2.0D and 3.5D) profiles are 2-inches deep and 3.5-inches deep, respectively. These profiles create a highly effective and value-added deck type for elevated floor systems. This deck type provides significant strength and capacity at longer spans and unique and effective hanging solution opportunities. Learn more about Dovetail Deck




Non-Composite Floor Deck

Vulcraft produces a wide variety of non-composite deck that supports the concrete slab until the slab is cured. These deck help to produce an efficient and economical structural floor solution for elevated floor systems. These decks come in a variety of finish options.

Vulcraft Non-Composite Floor Decks are IAPMO (IAPMO UES ER-652) and UL Listed. These decks are designed in accordance with the ANSI/Steel Deck Institute NC-2017 and RD-2017.

See Non-Composite Deck Design Information below for a quick reference on Vulcraft's non-composite floor deck options. For custom design information, please visit our Online Design Tools.

NON-COMPOSITE DECK DESIGN INFORMATION (ASD)

Vulcraft’s Non-Composite Deck is used as a foundation for floors, stairways, or mezzanines. The deck acts as a permanent base that supports the concrete and gives it lateral stability. Each type of form deck differs in terms of the weight of the concrete that it can support. The uniform load being supported generally is not a factor when selecting a non-composite deck because it is only being used to form concrete and not designed to provide positive reinforcement.

The depth of the slab and the support spacing needs to be considered when choosing non-composite deck. Vulcraft non-composite deck comes in several depths ranging from 9/16-inches (0.6C) to 3-inches (3.0C) and is available in a variety of finishes.

NON-COMPOSITE DECK DESIGN INFORMATION (LRFD)

Vulcraft’s Non-Composite Deck is used as a foundation for floors, stairways, or mezzanines. The deck acts as a permanent base that supports the concrete and gives it lateral stability. Each type of form deck differs in terms of the weight of the concrete that it can support. The uniform load being supported generally is not a factor when selecting a non-composite deck because it is only being used to form concrete and not designed to provide positive reinforcement.

The depth of the slab and the support spacing needs to be considered when choosing non-composite deck. Vulcraft non-composite deck comes in several depths ranging from 9/16-inches (0.6C) to 3-inches (3.0C) and is available in a variety of finishes.


Dovetail Deck

Vulcraft’s Dovetail Deck System uses the intrinsic strength and aesthetic appeal of the dovetail shape to provide the architectural and structural design communities with a variety of floor and roof deck design solutions.

The Vulcraft FormLok Dovetail Composite Floor Deck is one of our most versatile and practical products. You can achieve long spans with shallower floor depths that enable you to fit more into multi-story buildings.

Vulcraft's dovetail, acoustical and non-acoustical roof decks are IAPMO UES ER-423, UL and/or FM listed. See datasheets for specific listings.

Along with its aesthetic design, Vulcraft's dovetail roof deck provides excellent load capability. The acoustical roof decks use proven sound-reducing technology to help lower level of ambient background noise.

Dovetail decks are designed in accordance with the ANSI/Steel Deck Institute RD-2017.

LEARN MORE ABOUT DOVETAIL

Cellular Deck

Vulcraft Cellular Decking is ideal for exposed ceiling areas where a flat bottom ceiling is desired without compromising load capabilities. By acting as both a ceiling and roof, this versatile product combines the strength of roll formed steel with an aesthetically pleasing bottom plate. In addition, the expense and trouble of suspended ceilings is eliminated when you choose our acoustical option.

All Cellular acoustical and non-acoustical roof and floor decks are IAPMO UES ER-652, FM and/or UL Listed. See datasheets for specific listings. Vulcraft Cellular decks are designed in accordance with the ANSI/Steel Deck Institute RD-2017 and C-2017.

CELLULAR DECK ASD LOAD TABLES

1.5BP Cellular Deck (wide rib) deck utilizes the classic 1.5B roof deck with a full pan underneath. A variety of side-lap features are also available including interlocked (1.5BP) and PunchLok II connection (1.5PLBP). Learn More About the PunchLok II System

These profiles are also available with acoustical properties (1.5BPA and 1.5PLBPA).

1.5VLP, 2.0VLP and 3.0VLP Cellular Deck utilizes the 1.5VLI, 2.0VLI and 3.0VLI deck profiles, respectively, with a full pan underneath. A variety of side-lap features are also available for all three profiles including interlocked (1.5VLP, 2.0VLP and 3.0VLP) and PunchLok II connection (1.5PLVLP, 2.0PLVLP and 3.0PLVLP). Learn More About the PunchLok II System

These profiles are also available with acoustical properties (1.5VLPA,1.5PLVLPA, 2.0VLPA, 2.0PLVLPA, 3.0VLPA and 3.0PLVLPA).

3NP Cellular Deck utilizes the N-Deck profile with 3” deep ribs and a full pan underneath. The 3NP profile comes in 24” and 32” widths. It is also available with acoustical properties (3NPA) and using the PunchLok II System (3PLNP). Learn More About the PunchLok II System

CELLULAR DECK LRFD LOAD TABLES

1.5BP Cellular Deck (wide rib) deck utilizes the classic 1.5B roof deck with a full pan underneath. A variety of side-lap features are also available including interlocked (1.5BP) and PunchLok II connection (1.5PLBP). Learn More About the PunchLok II System

These profiles are also available with acoustical properties (1.5BPA and 1.5PLBPA).

1.5VLP, 2.0VLP and 3.0VLP Cellular Deck utilizes the 1.5VLI, 2.0VLI and 3.0VLI deck profiles, respectively, with a full pan underneath. A variety of side-lap features are also available for all three profiles including interlocked (1.5VLP, 2.0VLP and 3.0VLP) and PunchLok II connection (1.5PLVLP, 2.0PLVLP and 3.0PLVLP). Learn More About the PunchLok II System

These profiles are also available with acoustical properties (1.5VLPA,1.5PLVLPA, 2.0VLPA, 2.0PLVLPA, 3.0VLPA and 3.0PLVLPA).

3NP Cellular Deck utilizes the N-Deck profile with 3” deep ribs and a full pan underneath. The 3NP profile comes in 24” and 32” widths. It is also available with acoustical properties (3NPA) and using the PunchLok II System (3PLNP). Learn More About the PunchLok II System


PunchLok® II System

The Vulcraft PunchLok II System utilizes a specially designed pneumatic tool to achieve higher shear values at less cost through high quality side seam attachments. Used in conjunction with Vulcraft’s interlocking products, the PunchLok II tool is fast, effective, and provides a stronger and more positive attachment than screwed sidelaps or conventional button punches. It also provides excellent lateral diaphragm action, minimizes steel deck attachments, and potentially reduces steel deck gage. The PunchLok II tool is designed to be used Vulcraft’s 1.5PLB-36, 3PLN-32, 3PLN-24, 1.5PLVLI-36, 2PLVLI-36, and 3PLVLI-36 steel deck.

Features:

  • A weld-free system when used in conjunction with mechanical fasteners at supports.
  • As strong as top seam welds in most applications, but installs up to 10 times faster.
  • Requires no touch-up from either the topside or the bottom side of the deck.
  • Accuracy of the attachment can be inspected from the deck’s topside and requires no inspection tools or gages.

Learn More About the PunchLok II System
